Fiber & Twisted Pair Terminations
Professional Cable Termination Services
JSARK Telecom Inc. provides expert fiber optic and twisted pair termination services for data centers, telecommunications rooms, and enterprise networks. Our certified technicians ensure precise, low-loss connections that meet or exceed industry standards.
Our Termination Services Include:
- Fiber optic connector termination (SC, LC, ST, FC, MPO/MTP)
- Fusion splice-on connector (SOC) termination
- Cat5e, Cat6, Cat6a, Cat7, Cat8 twisted pair termination
- Keystone jack and patch panel termination
- Fiber enclosure and cassette installation
- Punch-down block and 110 block termination
- Field-terminated plug (RJ45) installation
- Shielded and unshielded twisted pair termination
Termination Methods
Precision termination for every cable type
Fiber Optic Termination
Professional fiber connector installation for single-mode and multi-mode fibers using epoxy/polish or pre-polished splice-on connector methods.
- Low insertion loss: ≤0.3dB typical
- High return loss: ≥55dB (UPC), ≥65dB (APC)
- All connector types: SC, LC, ST, FC, MPO
- 900µm, 2mm, 3mm cable compatibility
Twisted Pair Termination
Precision termination of copper cabling for high-speed Ethernet networks up to 40Gbps.
- Cat5e to Cat8 termination
- T568A and T568B wiring standards
- Keystone jack and patch panel termination
- Shielded (FTP/STP) and unshielded (UTP)
Fiber Optic Connector Types
We terminate all industry standard connectors
SC Connector
Square connector
Push-pull coupling
2.5mm ferrule
LC Connector
Small form factor
Push-pull latch
1.25mm ferrule
ST Connector
Straight tip
Bayonet coupling
2.5mm ferrule
FC Connector
Ferrule connector
Screw-on coupling
High vibration resistance
MPO/MTP
Multi-fiber array
12/24/48 fibers
High density
Fiber Termination Process
Step-by-step professional termination procedure
Strip
Remove outer jacket
Clean
Remove buffer coating
Cleave
Precision cut
Insert
Into connector
Crimp/Fuse
Secure connection
Inspect
Verify quality
Twisted Pair Termination Standards
T568A vs T568B Wiring
We follow both wiring standards as per customer requirements. T568B is most common in commercial installations, while T568A is often used in government projects. Both are ANSI/TIA-568 compliant.
Shielded Termination
For Cat6a, Cat7, and Cat8 installations, we properly terminate shielded cables including drain wire grounding and foil shield continuity for maximum EMI/RFI protection.
Strain Relief & Bend Radius
We maintain proper bend radius (4x cable diameter for twisted pair) and use appropriate strain relief boots to prevent cable damage at termination points.
Termination Tools
- Fusion splicer for SOC termination
- Precision fiber cleaver
- Fiber microscope (200x-400x)
- Punch-down tool (110/Krone)
- Cable strippers (fiber & copper)
- RJ45 crimping tool
- Cable tester & certifier
- Shield termination tools
Performance Specifications
We guarantee terminations that meet or exceed industry standards
| Cable Type | Max Insertion Loss | Return Loss | Test Standard |
|---|---|---|---|
| Single-mode Fiber (OS2) | ≤0.3dB per connector | ≥55dB (UPC) / ≥65dB (APC) | TIA-526-14 |
| Multi-mode Fiber (OM3/OM4) | ≤0.3dB per connector | ≥20dB | TIA-526-14 |
| Cat6 UTP | Next: ≥44.3dB @ 250MHz | ≥20.0dB @ 100MHz | TIA-568.2-D |
| Cat6a UTP/FTP | Next: ≥49.8dB @ 500MHz | ≥20.0dB @ 100MHz | TIA-568.2-D |
| Cat8.2 (25/40G) | Next: ≥59.8dB @ 2000MHz | ≥24.0dB @ 2000MHz | ANSI/TIA-568.2-D |
Quality Assurance
End-Face Inspection
Every fiber connector is inspected before and after termination using 400x microscope. We follow IEC 61300-3-35 cleanliness standards.
Certification Testing
All terminations are tested using Fluke DSX or EXFO OTDR equipment. We provide detailed test reports for every installed link.
Why Choose JSARK Telecom?
Certified Technicians
Our team holds BICSI Installer 2, Fiber Optic Association (FOA) certifications, and manufacturer-specific certifications.
Detailed Documentation
Complete termination records including connector type, loss values, and end-face inspection images.
Need Fiber or Twisted Pair Termination?
Contact JSARK Telecom Inc. today
Free consultation & quote - Certified terminations with full testing documentation
